Hasselblad XCD f4/28mm P
Added to basket!
Description:

Hasselblad XCD 4/28P - Lightweight, Wide-Angle Lens for Street Photography.
Measuring 43.5mm in length and 245g in weight, XCD 4/28P is the lightest and smallest lens of the Hasselblad X System and the lightest lens of the current medium format lens system. This portable and powerful lens allows you to capture the world in the palm of your hand.
Product Code:
HASSXCD28P
Hasselblad XCD f4/28mm P


Unparalleled Optical Performance, Immense Details.

Capturing a classic concert of light and shadow begins with the lens. XCD 4/28P adopts an optical structure of nine elements in eight groups, including two aspherical elements and one ED element, which ensures excellent imaging while effectively suppressing chromatic despersion. With a thoughtfully crafted arrangement, the lens has a compact size and a powerful performance, meeting the resolution requirements of 100 million pixels. The lens yields sharp imaging with high precision and high resolution from the centre to the edges, achieving stunning image quality across the frame.

A slightly wider angle enables distinctly bigger scenes. The wide-angle lens with a 22mm equivalent focal length and F4.0 aperture makes it easy to capture nature, street culture and urban architecture. With a 22cm minimum focusing distance and 1:6 magnification, rich close-ups of flowers, cuisine and much more are effortlessly captured.

Flexible Focusing - Capture a Fleeting Moment.


XCD 4/28P sports a linear stepping motor and a lighter, smaller focusing lens group. When used with the PDAF technology of X2D 100C, the focusing lens group can quickly reach the focusing position and achieve a precise stop. This results in fast, accurate, and responsive focusing, so your scene is captured before the click of the shutter.

Fast Leaf Shutter, Unlimited Creative Freedom.


The len's small but powerful leaf shutter supports shooting with flash synchronisation at all shutter speeds, with flash synchronisation up to 1/4000s. Shoot with flash in strong sunlight to capture dynamic subject juxtaposition, highlighting your subject while darkening the background.




GENERAL LENS DATA
Focal length: 28 mm
Equivalent Focal length (24x36): 22 mm
Aperture range: f/4 - f32
Angle of view diag/hor/vert: 89°/76°/60°
Length/diameter: 48 / 75 mm
Length (from camera lens mount flange): 43.5 mm
Weight (excl. covers): 245 g
Filter diameter: 72 mm
Product number: CP.HB.00000830.01

CLOSE FOCUS RANGE DATA
Minimum distance object to image plane: 0.22 m
Maximum image scale: 1:6.0
Corresponding area of coverage: 26 x 20 cm
Corresponding exposure reduction: 0. f-stops
